DC~40GHz, 2组六选一, 2.92, 网口控制, USB-B控制
要查看该商品是否有现货，请进入电子宝商城的“现货商品”中搜索。
对与本页内容的任何变更，恕不另行通知，订货前，请确认技术参数。
产品不可用于违法用途，违法使用造成的损失由客户承担。
宽带，大功率。
| 参数 | 最小 | 典型 | 最大 | 单位 |
| 工作频率 | DC | ~ | 40 | GHz |
| 插入损耗 | 0.5@DC-12GHz | dB | ||
| 插入损耗 | 0.7@12-18GHz | dB | ||
| 插入损耗 | 0.9@18-26.5GHz | dB | ||
| 插入损耗 | 1.2@26.5-40GHz | dB | ||
| 隔离度 | 70@DC-12GHz | dB | ||
| 隔离度 | 60@12-18GHz | dB | ||
| 隔离度 | 55@18-26.5GHz | dB | ||
| 隔离度 | 50@26.5-40GHz | dB | ||
| 驻波比 | 1.5@DC-12GHz | |||
| 驻波比 | 1.8@18-26.5GHz | |||
| 驻波比 | 2@26.5-40GHz | |||
| 平均功率 | 40@DC-6GHz | W | ||
| 平均功率 | 30@6-12GHz | W | ||
| 平均功率 | 25@12-18GHz | W | ||
| 平均功率 | 12@18-26.5GHz | W | ||
| 平均功率 | 5@26.5-40GHz | W |
| 开关时间 | 15ms |
| 开关路数 | 2组六选一 |
| 接口形式 | 2.92 |
| 接口材质 | 不锈钢 |
| 阻抗 | 50Ω |
| 工作电压 | +12VDC |
| 工作温度 | -25~+65℃设计保证 |
| 储存温度 | -40~+80℃设计保证 |
| 开关寿命 | 200万次 |
| 控制方式 | 网口控制，USB-B控制 |
| 1 | 分路端口 | J1,J2,J3,J4,J5,J6,J7,J8,J9,J10,J11,J12 |
| 2 | 公共端口 | JC1,JC2 |
| The name of the command | Feature description | Command format | Command direction | Successful response | Failure response |
| Switch queries | Switch status query | ReadSW:01 | PC-->Switch | SW:01,V1 , V2 ,END | Fail |
| Switch settings | Switch settings | SetSW:01,K01,XX | Switch --> PC | OK | Fail |
| Model inquiry | Get the device model | *IDN? | PC-->Switch | XXXXXX, RENEW, SN123456789, SV004 | Fail |
| Device model settings | Device model settings | SET IDN:model | Switch --> PC | OK | Fail |
| Network interface setting command | Change the IP address, default gateway, subnet mask, and port number at the same time | SetNETWORK:Address-Gateway-Mask-Port Number | PC-->Switch | OK | Fail |
| Network interface query command | Query the IP address, default gateway, subnet mask, and port number at the same time | LstNETWORK | PC-->Switch | IP:address-NETGATE:gateway-NETMASK:mask-PORT:Port number | Fail |
1、The device defaults as a TCP/ip server；
2、Default IP address: 192.168.1.100；
3、Default port number: 3000;
4、Baud rate: 9600
| The name of the command | Feature description | Command format | Command direction | Successful response | Failure response |
| IP Query commands | Query the IP address of the switch control board | LstIP | PC-->Switch | IP:address | Fail |
| Subnet mask setting command | Modify the subnet mask of the switch board | SetNetMask:parameter | PC-->Switch | OK | Fail |
| Subnet mask query command | Query the subnet mask of the switch control board | LstNetMask | PC-->Switch | NetMask:Subnet mask | Fail |
| Default gateway setup command | Modify the IP address of the switch board | SetNetGate:Default gateway | PC-->Switch | OK | Fail |
| The default gateway query command | Query the default gateway of the switch dashboard | LstNetGate | PC-->Switch | NetGate:Default gateway | Fail |
| Port number setting command | Modify the port number of the switch control board | SetPORT:parameter1 | PC-->Switch | Disconnect from the network | SetPORTFail |
| Port number query command | Query the port number of the switch control board | LstPORT | PC-->Switch | The PORT address is Port number | None |
| IP Set commands | Modify the IP address of the switch board | SetIP:address | PC-->Switch | OK | Fail |
| 1 | 清洗产品表面，请勿将产品浸泡清洗液中清洗。 |
| 2 | 整体温度大于125℃的情况，订货前与我们协商。 |
提供技术要求，工程师 1 个工作日内响应。
